Machining-center
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| horizontal-machining | YBM-900N-100RP | YASDA PRECISION TOOLS K.K. | [Travel] X...1,500 Y...1,400 Z...1,100 [APC] ...36 [ATC] ...240 |
| horizontal-machining | YBM8T | YASDA PRECISION TOOLS K.K. | [Travel] X...1,250 Y...1,300 Z...1,000 [APC] ...10 [ATC] ...240 |
| horizontal-machining | HS6A | MITSUI SEIKI CO.,LTD. | [Travel] X...1,300 Y...1,000 Z...1,000 [APC] ...6 [ATC] ...270 |
| Vertical machining | MB46VE | Okuma Corporation | [Travel] X...762 Z...460 [ATC] ...32 |
| Five-face machinie | MCR-A5C-25X50 | Okuma Corporation | [Travel] X...5,200 Y...3,000 Z...650 [APC] ...2 [ATC] ...180 |
| Five-face machinie | MCR-A5C-30X50 | Okuma Corporation | [Travel] X...5,200 Y...3,500 Z...650 [APC] ...2 [ATC] ...180 |
| Five-axis machinie | YBM Vi40 | YASDA PRECISION TOOLS K.K. | [Travel] X...900 Y...500 Z...450 [APC] ...2 [ATC] ...60 |
horizontal-machining / YBM-900N-100RP / YASDA PRECISION TOOLS K.K.
Jig Borer
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| NC Jig boring machine | 7CN | MITSUI SEIKI CO.,LTD. | [Travel] X...1,000 Y...1,500 Z...300 [APC] ...1 [ATC] ...20 |
| CNC Jig Borer | YBM9150V | YASDA PRECISION TOOLS K.K. | [Travel] X...1,500 Y...900 Z...450 [APC] ...1 [ATC] ...60 |
Grinder
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| Ultra precision Forming Surface Grinder | 1SGC-156E | NAGASE INTEGREX CO., LTD. | [Travel] X...1,500 Y...600 Z...500 |
| Cylindrical Grinders | G32 | Toyoda Machine Works Ltd. | [Travel] X...φ200 Z...1,000 |
| Internal Grinders | GC32 | Toyoda Machine Works Ltd. | [Travel] X...φ300 Z...1000 |
| Ultra precision Internal Grinding Machine | IGM-2TM | Okamoto Machine Tool Works,Ltd. | [Travel] X...φ200 Z...200 |
Electric discharge machines
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| Wire-cut EDM | AQ750L | Sodick Co.,Ltd. | [Travel] X...750 Y...500 Z...400 |
| Wire-cut EDM | HS-70A | Brother | [travel] 410×260mm |
| Wire-cut | AQ1200L | Sodick Co.,Ltd. | [travel] X...400 Y...800 Z...1,200 |
Boring Machine
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| Boring Machine | BTD110,R16 | TOSHIBA MACHINE CO.,LTD | [Travel] X...2,000 Y...1,500 Z...1,450 W...500 [ATC] ...38 |
Multi-axis Machines
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| INTEGREX | INTEGREX300-Ⅲ | YAMAZAKI MAZAK CORPORATION. | [Max machining dia] φ760mm [Max work length] φ1,532mm [ATC] ...80 |
| INTEGREX | INTEGREX30 | YAMAZAKI MAZAK CORPORATION. | [Max machining dia] φ510mm [Max work length] φ1,539mm [ATC] ...40 |
| INTEGREX | INTEGREX300-Ⅳ | YAMAZAKI MAZAK CORPORATION. | [Max machining dia] φ760mm [Max work length] φ1,524mm [ATC] ...120 |
Measuring Machines
| Type | Model | Manufacturer | Specifications |
|---|---|---|---|
| Coordinate Measuring Machines | PMM-C8106P | Leitz | [Travel] X...800 Y...1,000 Z...580 |
| Coordinate Measuring Machines | FALCIO APEX | Mitutoyo Corporation | [Travel] X...1,200 Y...2,000 Z...1,000 |
| Roundness and Cylindrical Profile Measuring Instruments | RONDCOM50A RONDCOM72A | TOKYO SEIMITSU CO., LTD. |
Coordinate Measuring Machines / PMM-C8106P / Leitz
Equipment list
| Type | Manufacturer | No. of units |
|---|---|---|
| horizontal-machining（#50） | YASDA PRECISION TOOLS K.K. | 3 |
| horizontal-machining（#50） | MITSUI SEIKI CO.,LTD. | 1 |
| horizontal-machining（#50） | TOSHIBA MACHINE | 1 |
| Five-face machinie（#50） | Okuma Corporation | 2 |
| Vertical machining（#50） | MITSUI SEIKI CO.,LTD. | 1 |
| Vertical machining（#50） | Okuma Corporation | 3 |
| ROBODRIL L（#30） | FANUC | 1 |
| Five-axis machinie（#40） | YASDA PRECISION TOOLS K.K. | 1 |
| Multi-axis Machines（INTEGREX） | YAMAZAKI MAZAK CORPORATION. | 4 |
| Wire-cut EDM | Sodick Co.,Ltd. | 3 |
| Machine | NIIGATA MACHINE TECHNO Co., Ltd. | 1 |
| Machine | CHUO-SEIKI CO., LTD. | 1 |
| Drill press | Okuma Corporation | 1 |
| Milling machine | MAKINO | 1 |
| Milling machine | OKK | 1 |
| Lathes | Okuma Corporation | 1 |
| Lathes | Takisawa Machine Tool Co., Ltd. | 1 |
| Internal Grinding Machines | Okamoto | 1 |
| Internal Grinding Machines | JTEKT | 1 |
| External Grinding Machines | JTEKT | 2 |
| Forming Surface Grinder（Max） | NAGASE INTEGREX CO., LTD. | 3 |
| Forming Surface Grinder（Minimum） | NAGASE INTEGREX CO., LTD. | 1 |
| Vertical Jig Borer | YASDA PRECISION TOOLS K.K. | 1 |
| Jig Borer | MITSUI SEIKI CO.,LTD. | 1 |
| Coordinate Measuring Machines | Mitutoyo Corporation | 1 |
| Coordinate Measuring Machines | Leitz | 1 |
| Coordinate Measuring Machines | TOKYO SEIMITSU CO., LTD. | 1 |
| Roundness and Cylindrical Profile Measuring Instruments | TOKYO SEIMITSU CO., LTD. | 2 |
| Contour Measuring Instruments | TOKYO SEIMITSU CO., LTD. | 1 |
| total 43 | ||
